IXBH10N300HV

Part No :: IXBH10N300HV

Manufacturer: Wickmann / Littelfuse

VIGOR # :: 2915928

Description: IGBT 3000V 20A 140W TO247AD

Catalog: Transistors - IGBTs - Single

DataSheet: IXBH10N300HV PDF

Country of origin: -

Date code: -

IXBH10N300HV Specifications

Type	Description
Series:	BIMOSFET™
Package:	Tube
Part Status:	Active
IGBT Type:	-
Voltage - Collector Emitter Breakdown (Max):	3000 V
Current - Collector (Ic) (Max):	34 A
Current - Collector Pulsed (Icm):	88 A
Vce(on) (Max) @ Vge, Ic:	2.8V @ 15V, 10A
Power - Max:	180 W
Switching Energy:	-
Input Type:	Standard
Gate Charge:	46 nC
Td (on/off) @ 25°C:	36ns/100ns
Test Condition:	960V, 10A, 10Ohm, 15V
Reverse Recovery Time (trr):	1.6 µs
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Supplier Device Package:	TO-263

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 0

Shipped from

HK warehouse

Expected Shipping Date

Dec 29 - Jan 02 2025

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$53.17~~	~~$53.17~~
30	~~$53.17~~	~~$1 595.09~~

Current price of IXBH10N300HV is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
