STGD20N40LZ

Part No :: STGD20N40LZ

Manufacturer: STMicroelectronics

VIGOR # :: 2916039

Description: IGBT 390V 25A 125W DPAK

Catalog: Transistors - IGBTs - Single

DataSheet: STGD20N40LZ PDF

Country of origin: -

Date code: -

STGD20N40LZ Specifications

Type	Description
Series:	Automotive, AEC-Q101, PowerMESH™
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
IGBT Type:	-
Voltage - Collector Emitter Breakdown (Max):	390 V
Current - Collector (Ic) (Max):	25 A
Current - Collector Pulsed (Icm):	40 A
Vce(on) (Max) @ Vge, Ic:	1.6V @ 4V, 6A
Power - Max:	125 W
Switching Energy:	-
Input Type:	Logic
Gate Charge:	24 nC
Td (on/off) @ 25°C:	700ns/4.3µs
Test Condition:	300V, 10A, 1kOhm, 5V
Reverse Recovery Time (trr):	-
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package:	DPAK
