NGTB40N120IHLWG

Part No :: NGTB40N120IHLWG

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 4589217

Description: IGBT 1200V 40A TO247

Catalog: Transistors - IGBTs - Single

DataSheet: NGTB40N120IHLWG PDF

Country of origin: -

Date code: -

NGTB40N120IHLWG Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
IGBT Type:	Trench Field Stop
Voltage - Collector Emitter Breakdown (Max):	1200 V
Current - Collector (Ic) (Max):	80 A
Current - Collector Pulsed (Icm):	320 A
Vce(on) (Max) @ Vge, Ic:	2.35V @ 15V, 40A
Power - Max:	260 W
Switching Energy:	1.4mJ (off)
Input Type:	Standard
Gate Charge:	420 nC
Td (on/off) @ 25°C:	-/360ns
Test Condition:	600V, 40A, 10Ohm, 15V
Reverse Recovery Time (trr):	-
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Package / Case:	TO-247-3
Supplier Device Package:	TO-247
