SGH23N60UFDTU

SGH23N60UFDTU

Image is for reference,
please contact us to get the real picture

Part No :

SGH23N60UFDTU

Manufacturer
Sanyo Semiconductor/ON Semiconductor
Description
IGBT 600V 23A 100W TO3P
Catalog
Transistors - IGBTs - Single
Shipped from
HK warehouse
Expected Shipping Date
Oct 15 - Oct 19 2025
DataSheet
SGH23N60UFDTU PDF
Availability
0 pieces
Unit Price
$0.00000

Current price of SGH23N60UFDTU is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

SGH23N60UFDTU Specifications
Type Description
Series:-
Package:Tube
Part Status:Obsolete
IGBT Type:-
Voltage - Collector Emitter Breakdown (Max):600 V
Current - Collector (Ic) (Max):23 A
Current - Collector Pulsed (Icm):92 A
Vce(on) (Max) @ Vge, Ic:2.6V @ 15V, 12A
Power - Max:100 W
Switching Energy:115µJ (on), 135µJ (off)
Input Type:Standard
Gate Charge:49 nC
Td (on/off) @ 25°C:17ns/60ns
Test Condition:300V, 12A, 23Ohm, 15V
Reverse Recovery Time (trr):60 ns
Operating Temperature:-55°C ~ 150°C (TJ)
Mounting Type:Through Hole
Package / Case:TO-3P-3, SC-65-3
Supplier Device Package:TO-3PN
