| Type | Description |
|---|---|
| Series: | UF318AAA |
| Package: | Bulk |
| Part Status: | Active |
| Voltage - Rated: | 230VAC |
| Size / Dimension: | Round - 318mm Dia |
| Width: | 154.4mm |
| Air Flow: | 1165.0 CFM (32.62m³/min) |
| Static Pressure: | 1.600 in H2O (398.6 Pa) |
| Bearing Type: | Ball |
| Fan Type: | Motorized Impellers |
| Features: | Permanent Split Capacitor Motor, Thermal Overload Protector (TOP) |
| Noise: | 66.0dB(A) |
| Power (Watts): | 160W |
| RPM: | 1580 RPM |
| Termination: | 2 Wire Leads |
| Ingress Protection: | - |
| Operating Temperature: | -4 ~ 158°F (-20 ~ 70°C) |
| Approval Agency: | CE, cUL, TUV, UL |
| Weight: | 8.3 lbs (3.8 kg) |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 10 | ||
| 25 | ||
| 50 |
Current price of UF318AAA23-H1C4A is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
