| Type | Description |
|---|---|
| Series: | 09225SA |
| Package: | Box |
| Part Status: | Active |
| Voltage - Rated: | 24VDC |
| Size / Dimension: | Square - 92mm L x 92mm H |
| Width: | 25.00mm |
| Air Flow: | 35.7 CFM (1.00m³/min) |
| Static Pressure: | 0.090 in H2O (22.4 Pa) |
| Bearing Type: | Ball |
| Fan Type: | Tubeaxial |
| Features: | Speed Sensor (Tach) |
| Noise: | 25.0dB |
| Power (Watts): | 840 mW |
| RPM: | 2050 RPM |
| Termination: | 3 Wire Leads |
| Ingress Protection: | - |
| Operating Temperature: | 14 ~ 158°F (-10 ~ 70°C) |
| Approval Agency: | CE, UL, VDE |
| Weight: | 0.209 lb (94.8 g) |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 90 |
Current price of 3610SB-05W-B29-E50 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
