| Type | Description |
|---|---|
| Series: | 09225VA |
| Package: | Box |
| Part Status: | Active |
| Voltage - Rated: | 24VDC |
| Size / Dimension: | Square - 92mm L x 92mm H |
| Width: | 25.00mm |
| Air Flow: | 96.4 CFM (2.70m³/min) |
| Static Pressure: | 0.602 in H2O (149.9 Pa) |
| Bearing Type: | Ball |
| Fan Type: | Tubeaxial |
| Features: | - |
| Noise: | 51.0dB(A) |
| Power (Watts): | 9.12 W |
| RPM: | 5600 RPM |
| Termination: | 2 Wire Leads |
| Ingress Protection: | - |
| Operating Temperature: | 14 ~ 158°F (-10 ~ 70°C) |
| Approval Agency: | CE, UL, VDE |
| Weight: | 0.298 lb (135.17 g) |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 10 | ||
| 25 | ||
| 50 | ||
| 100 | ||
| 250 | ||
| 500 |
Current price of 3610VL-05W-B70-B00 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
