| Type | Description |
|---|---|
| Series: | 08025SA |
| Package: | Box |
| Part Status: | Active |
| Voltage - Rated: | 24VDC |
| Size / Dimension: | Square - 80mm L x 80mm H |
| Width: | 25.00mm |
| Air Flow: | 36.0 CFM (1.01m³/min) |
| Static Pressure: | 0.116 in H2O (29.0 Pa) |
| Bearing Type: | Ball |
| Fan Type: | Tubeaxial |
| Features: | - |
| Noise: | 26.0dB(A) |
| Power (Watts): | 1.44 W |
| RPM: | 2700 RPM |
| Termination: | 2 Wire Leads |
| Ingress Protection: | - |
| Operating Temperature: | 14 ~ 158°F (-10 ~ 70°C) |
| Approval Agency: | CE, CSA, UL, VDE |
| Weight: | 0.176 lb (79.83 g) |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 80 |
Current price of 3110SB-05W-B40-B00 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
