| Type | Description |
|---|---|
| Series: | BM |
| Package: | Box |
| Part Status: | Active |
| Voltage - Rated: | 12VDC |
| Size / Dimension: | Rectangular/Rounded - 44mm L x 45mm H |
| Width: | 15.00mm |
| Air Flow: | 3.0 CFM (0.084m³/min) |
| Static Pressure: | 0.642 in H2O (159.9 Pa) |
| Bearing Type: | Ball |
| Fan Type: | Blower |
| Features: | Locked Rotor Sensor |
| Noise: | 39.0dB |
| Power (Watts): | 1.68 W |
| RPM: | 6500 RPM |
| Termination: | 3 Wire Leads |
| Ingress Protection: | - |
| Operating Temperature: | 14 ~ 158°F (-10 ~ 70°C) |
| Approval Agency: | CE, CSA, UL, VDE |
| Weight: | 0.055 lb (24.95 g) |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 240 |
Current price of BM4515-04W-B40-L00 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
