| Type | Description |
|---|---|
| Series: | HPLC, FDD1-17251 |
| Package: | Bulk |
| Part Status: | Active |
| Voltage - Rated: | 24VDC |
| Size / Dimension: | Rectangular/Rounded - 172mm L x 151mm H |
| Width: | 51.00mm |
| Air Flow: | 220.0 CFM (6.16m³/min) |
| Static Pressure: | 0.571 in H2O (142.2 Pa) |
| Bearing Type: | Ball |
| Fan Type: | Tubeaxial |
| Features: | Locked Rotor Sensor, Speed Sensor (Tach) |
| Noise: | 52.0dB(A) |
| Power (Watts): | 15.6 W |
| RPM: | 2800 RPM |
| Termination: | 4 Wire Leads |
| Ingress Protection: | IP56M - Dust Protected, Water Resistant |
| Operating Temperature: | -4 ~ 158°F (-20 ~ 70°C) |
| Approval Agency: | CE, cURus, TUV |
| Weight: | 2.5 lbs (1.1 kg) |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 12 |
Current price of FDD1-17251DBAW3C-L56 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
