SN12-500

Part No :: SN12-500

Manufacturer: KEMET

Description: NMC 100.0UH 5.0A 0.0400 OHM TH

Catalog: Common Mode Chokes

DataSheet: SN12-500 PDF

Availability: 196 pieces

Current price of SN12-500 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SN12-500 Specifications

Type	Description
Series:	SN
Package:	Bulk
Part Status:	Active
Filter Type:	Power Line
Number of Lines:	2
Impedance @ Frequency:	-
Inductance @ Frequency:	100 µH @ 100 kHz
Frequency Coupled to Inductance @ Frequency:	-
Current Rating (Max):	5A
DC Resistance (DCR) (Max):	40mOhm
Voltage Rating - DC:	-
Voltage Rating - AC:	-
Operating Temperature:	-25°C ~ 105°C
Ratings:	-
Approval Agency:	-
Features:	-
Mounting Type:	Through Hole
Size / Dimension:	1.024" Dia x 0.472" W (26.00mm x 12.00mm)
Height (Max):	1.083" (27.50mm)
Package / Case:	Vertical, No Base, 2 PC Pin
