SRF0703-681M

Part No :: SRF0703-681M

Manufacturer: J.W. Miller / Bourns

Description: INDUCT ARRAY 2 COIL 680UH SMD

Catalog: Arrays, Signal Transformers

DataSheet: SRF0703-681M PDF

Availability: 2555 pieces

Unit Price: ~~$0.96000~~

Current price of SRF0703-681M is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SRF0703-681M Specifications

Type	Description
Series:	SRF0703
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Number of Coils:	2
Inductance - Connected In Parallel:	680 µH
Inductance - Connected In Series:	2.72 mH
Tolerance:	±20%
Current Rating - Parallel:	290 mA
Current Rating - Series:	143 mA
Current Saturation - Parallel:	310 mA
Current Saturation - Series:	150 mA
DC Resistance (DCR) - Parallel:	3.96Ohm Max
DC Resistance (DCR) - Series:	16.17Ohm Max
Shielding:	Shielded
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Size / Dimension:	0.299" L x 0.299" W (7.60mm x 7.60mm)
Height:	0.142" (3.60mm)
