B82442H1154K000

Part No :: B82442H1154K000

Manufacturer: TDK EPCOS

Description: FIXED IND 150UH 290MA 1.76 OHM

Catalog: Fixed Inductors

DataSheet: B82442H1154K000 PDF

Availability: 0 pieces

Current price of B82442H1154K000 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

B82442H1154K000 Specifications

Type	Description
Series:	SIMID
Package:	Tape & Reel (TR)
Part Status:	Last Time Buy
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	150 µH
Tolerance:	±10%
Current Rating (Amps):	290 mA
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	1.76Ohm Max
Q @ Freq:	20 @ 796kHz
Frequency - Self Resonant:	4.8MHz
Ratings:	AEC-Q200
Operating Temperature:	-55°C ~ 150°C
Inductance Frequency - Test:	796 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	2-SMD, J-Lead
Supplier Device Package:	2220 (5650 Metric)
Size / Dimension:	0.220" L x 0.197" W (5.60mm x 5.00mm)
Height - Seated (Max):	0.209" (5.30mm)

Please confirm the specifications of the products when ordering.
