SRP1250-R56M

Part No :: SRP1250-R56M

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 560NH 36A 1.5 MOHM SMD

Catalog: Fixed Inductors

DataSheet: SRP1250-R56M PDF

Availability: 0 pieces

Unit Price: ~~$0.89760~~

Current price of SRP1250-R56M is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SRP1250-R56M Specifications

Type	Description
Series:	SRP1250
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Wirewound
Material - Core:	Iron
Inductance:	560 nH
Tolerance:	±20%
Current Rating (Amps):	36 A
Current - Saturation (Isat):	55A
Shielding:	Shielded
DC Resistance (DCR):	1.5mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-55°C ~ 150°C
Inductance Frequency - Test:	100 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.547" L x 0.531" W (13.90mm x 13.50mm)
Height - Seated (Max):	0.232" (5.90mm)
