SD20-8R2-R

Part No :: SD20-8R2-R

Manufacturer: PowerStor (Eaton)

Description: FIXED IND 8.2UH 1.61A 100 MOHM

Catalog: Fixed Inductors

DataSheet: SD20-8R2-R PDF

Availability: 0 pieces

Current price of SD20-8R2-R is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SD20-8R2-R Specifications

Type	Description
Series:	SD
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	8.2 µH
Tolerance:	±20%
Current Rating (Amps):	1.61 A
Current - Saturation (Isat):	966mA
Shielding:	Shielded
DC Resistance (DCR):	100mOhm
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-40°C ~ 85°C
Inductance Frequency - Test:	100 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.205" L x 0.205" W (5.20mm x 5.20mm)
Height - Seated (Max):	0.079" (2.00mm)

Please confirm the specifications of the products when ordering.
