SDR0503-562JL

Part No :: SDR0503-562JL

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 5.6MH 38MA 72 OHM SMD

Catalog: Fixed Inductors

DataSheet: SDR0503-562JL PDF

Availability: 445 pieces

Current price of SDR0503-562JL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SDR0503-562JL Specifications

Type	Description
Series:	SDR0503
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	5.6 mH
Tolerance:	±5%
Current Rating (Amps):	38 mA
Current - Saturation (Isat):	50mA
Shielding:	Unshielded
DC Resistance (DCR):	72Ohm Max
Q @ Freq:	40 @ 252kHz
Frequency - Self Resonant:	1MHz
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	1 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.197" L x 0.189" W (5.00mm x 4.80mm)
Height - Seated (Max):	0.130" (3.30mm)

Please confirm the specifications of the products when ordering.
