LQM18PZ1R0MCHD

Part No :: LQM18PZ1R0MCHD

Manufacturer: TOKO / Murata

Description: FIXED IND 1UH 950MA 290 MOHM

Catalog: Fixed Inductors

DataSheet: LQM18PZ1R0MCHD PDF

Availability: 5812 pieces

Current price of LQM18PZ1R0MCHD is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

LQM18PZ1R0MCHD Specifications

Type	Description
Series:	LQM18
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Multilayer
Material - Core:	Ferrite
Inductance:	1 µH
Tolerance:	±20%
Current Rating (Amps):	950 mA
Current - Saturation (Isat):	600mA
Shielding:	Shielded
DC Resistance (DCR):	290mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	80MHz
Ratings:	AEC-Q200
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	1 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	0603 (1608 Metric)
Supplier Device Package:	0603 (1608 Metric)
Size / Dimension:	0.063" L x 0.031" W (1.60mm x 0.80mm)
Height - Seated (Max):	0.026" (0.65mm)
