| Type | Description |
|---|---|
| Series: | PA4548.XXXNLT |
| Package: | Tape & Reel (TR)Cut Tape (CT) |
| Part Status: | Active |
| Type: | Molded |
| Material - Core: | - |
| Inductance: | 4.7 µH |
| Tolerance: | ±20% |
| Current Rating (Amps): | 4.6 A |
| Current - Saturation (Isat): | 8A |
| Shielding: | Unshielded |
| DC Resistance (DCR): | 50mOhm Max |
| Q @ Freq: | - |
| Frequency - Self Resonant: | - |
| Ratings: | - |
| Operating Temperature: | -40°C ~ 125°C |
| Inductance Frequency - Test: | 100 kHz |
| Features: | - |
| Mounting Type: | Surface Mount |
| Package / Case: | Nonstandard |
| Supplier Device Package: | - |
| Size / Dimension: | 0.276" L x 0.260" W (7.00mm x 6.60mm) |
| Height - Seated (Max): | 0.094" (2.40mm) |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 |
Current price of PA4548.472NLT is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
