PM13560S-100M

Part No :: PM13560S-100M

Manufacturer: J.W. Miller / Bourns

VIGOR # :: 4442336

Description: FIXED IND 10UH 7.5A 14.9MOHM SMD

Catalog: Fixed Inductors

DataSheet: PM13560S-100M PDF

Country of origin: -

Date code: -

PM13560S-100M Specifications

Type	Description
Series:	PM13560S
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Obsolete
Type:	Wirewound
Material - Core:	Iron
Inductance:	10 µH
Tolerance:	±20%
Current Rating (Amps):	7.5 A
Current - Saturation (Isat):	-
Shielding:	Shielded
DC Resistance (DCR):	14.9mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-40°C ~ 150°C
Inductance Frequency - Test:	100 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.547" L x 0.531" W (13.90mm x 13.50mm)
Height - Seated (Max):	0.232" (5.90mm)
