PM1038S-2R5M

Part No :: PM1038S-2R5M

Manufacturer: J.W. Miller / Bourns

VIGOR # :: 4444359

Description: FIXED IND 2.5UH 11.5A 8.7MOHM SM

Catalog: Fixed Inductors

DataSheet: PM1038S-2R5M PDF

Country of origin: -

Date code: -

PM1038S-2R5M Specifications

Type	Description
Series:	PM1038S
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Type:	-
Material - Core:	Iron
Inductance:	2.5 µH
Tolerance:	±20%
Current Rating (Amps):	11.5 A
Current - Saturation (Isat):	-
Shielding:	Shielded
DC Resistance (DCR):	8.7mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-40°C ~ 150°C
Inductance Frequency - Test:	100 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.465" L x 0.413" W (11.80mm x 10.50mm)
Height - Seated (Max):	0.165" (4.20mm)
