IMS05WDRU3R3K40

Part No :: IMS05WDRU3R3K40

Manufacturer: Vishay / Dale

VIGOR # :: 8202954

Description: FIXED IND 3.3UH 1.03A 310 MOHM

Catalog: Fixed Inductors

DataSheet: IMS05WDRU3R3K40 PDF

Country of origin: -

Date code: -

IMS05WDRU3R3K40 Specifications

Type	Description
Series:	IMS-5WD-40
Package:	-
Part Status:	Obsolete
Type:	-
Material - Core:	Iron
Inductance:	3.3 µH
Tolerance:	±10%
Current Rating (Amps):	1.03 A
Current - Saturation (Isat):	1.03A
Shielding:	Shielded
DC Resistance (DCR):	310mOhm Max
Q @ Freq:	40 @ 7.9MHz
Frequency - Self Resonant:	73MHz
Ratings:	-
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	7.9 MHz
Features:	-
Mounting Type:	Through Hole
Package / Case:	Axial
Supplier Device Package:	-
Size / Dimension:	0.164" Dia x 0.450" L (4.17mm x 11.43mm)
Height - Seated (Max):	-
