MC14046BDWG

Part No :: MC14046BDWG

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 3875882

Description: IC PHASE LOCKED LOOP 16-SOIC

Catalog: Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers

DataSheet: MC14046BDWG PDF

Country of origin: -

Date code: -

MC14046BDWG Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Type:	Phase Lock Loop (PLL)
PLL:	Yes
Input:	CMOS
Output:	CMOS
Number of Circuits:	1
Ratio - Input:Output:	2:2
Differential - Input:Output:	No/No
Frequency - Max:	1.9MHz
Divider/Multiplier:	No/No
Voltage - Supply:	3V ~ 18V
Operating Temperature:	-55°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	16-SOIC
