DS1284

Part No :: DS1284

Manufacturer: Maxim Integrated

VIGOR # :: 4839340

Description: IC RTC CLK/CALENDAR PAR 28-DIP

Catalog: Clock/Timing - Real Time Clocks

DataSheet: DS1284 PDF

Country of origin: -

Date code: -

DS1284 Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Type:	Clock/Calendar
Features:	Alarm, Leap Year, Square Wave Output, SRAM, Watchdog Timer
Memory Size:	50B
Time Format:	HH:MM:SS:hh (12/24 hr)
Date Format:	YY-MM-DD-dd
Interface:	Parallel
Voltage - Supply:	4.5V ~ 5.5V
Voltage - Supply, Battery:	2.4V ~ 3.5V
Current - Timekeeping (Max):	7mA @ 5V
Operating Temperature:	0°C ~ 70°C
Mounting Type:	Through Hole
Package / Case:	28-DIP (0.600", 15.24mm)
Supplier Device Package:	28-PDIP
