AD558JN

Part No :: AD558JN

Manufacturer: VIGOR

VIGOR # :: 3794276

Description: DACPORT MICROPROCESSOR 8-BIT DAC

Catalog: Data Acquisition - Digital to Analog Converters (DAC)

DataSheet: AD558JN PDF

Country of origin: -

Date code: -

AD558JN Specifications

Type	Description
Series:	DACPORT®
Package:	Tube
Part Status:	Obsolete
Number of Bits:	8
Number of D/A Converters:	1
Settling Time:	3µs
Output Type:	Voltage - Buffered
Differential Output:	No
Data Interface:	Parallel
Reference Type:	Internal
Voltage - Supply, Analog:	4.5V ~ 16.5V
Voltage - Supply, Digital:	4.5V ~ 16.5V
INL/DNL (LSB):	±0.5 (Max), -
Architecture:	R-2R
Operating Temperature:	0°C ~ 70°C
Package / Case:	16-DIP (0.300", 7.62mm)
Supplier Device Package:	16-PDIP
Mounting Type:	Through Hole

Alternative Products

Part Number	Manufacturer & Description	Compare
AD558JNZ Match 100%	Linear Technology (Analog Devices, Inc.) IC DAC 8BIT V-OUT 16DIP	AD558JN vs AD558JNZ
