AD558JNZ

Part No :: AD558JNZ

Manufacturer: Linear Technology (Analog Devices, Inc.)

VIGOR # :: 3798002

Description: IC DAC 8BIT V-OUT 16DIP

Catalog: Data Acquisition - Digital to Analog Converters (DAC)

DataSheet: AD558JNZ PDF

Country of origin: -

Date code: -

AD558JNZ Specifications

Type	Description
Series:	DACPORT®
Package:	Tube
Part Status:	Active
Number of Bits:	8
Number of D/A Converters:	1
Settling Time:	3µs
Output Type:	Voltage - Buffered
Differential Output:	No
Data Interface:	Parallel
Reference Type:	Internal
Voltage - Supply, Analog:	4.5V ~ 16.5V
Voltage - Supply, Digital:	4.5V ~ 16.5V
INL/DNL (LSB):	±0.5 (Max), -
Architecture:	R-2R
Operating Temperature:	0°C ~ 70°C
Package / Case:	16-DIP (0.300", 7.62mm)
Supplier Device Package:	16-PDIP
Mounting Type:	Through Hole

Alternative Products

Part Number	Manufacturer & Description	Compare
AD558JN Match 100%	VIGOR DACPORT MICROPROCESSOR 8-BIT DAC	AD558JNZ vs AD558JN
