MC56F8002VWLR

Part No :: MC56F8002VWLR

Manufacturer: NXP Semiconductors

VIGOR # :: 3617107

Description: IC MCU 16BIT 12KB FLASH 28SOIC

Catalog: Embedded - Microcontrollers

DataSheet: MC56F8002VWLR PDF

Country of origin: -

Date code: -

MC56F8002VWLR Specifications

Type	Description
Series:	56F8xxx
Package:	Tape & Reel (TR)
Part Status:	Active
Core Processor:	56800E
Core Size:	16-Bit
Speed:	32MHz
Connectivity:	I²C, LINbus, SCI, SPI
Peripherals:	LVD, POR, PWM, WDT
Number of I/O:	23
Program Memory Size:	12KB (6K x 16)
Program Memory Type:	FLASH
EEPROM Size:	-
RAM Size:	1K x 16
Voltage - Supply (Vcc/Vdd):	1.8V ~ 3.6V
Data Converters:	A/D 15x12b
Oscillator Type:	Internal
Operating Temperature:	-40°C ~ 105°C (TA)
Mounting Type:	Surface Mount
Package / Case:	28-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	28-SOIC
