R5F100EAGNA#20

Part No :: R5F100EAGNA#20

Manufacturer: Renesas Electronics America

VIGOR # :: 3633452

Description: IC MCU 16BIT 16KB FLASH 40HWQFN

Catalog: Embedded - Microcontrollers

DataSheet: R5F100EAGNA#20 PDF

Country of origin: -

Date code: -

R5F100EAGNA#20 Specifications

Type	Description
Series:	RL78/G13
Package:	Tray
Part Status:	Active
Core Processor:	RL78
Core Size:	16-Bit
Speed:	32MHz
Connectivity:	CSI, I²C, LINbus, UART/USART
Peripherals:	DMA, LVD, POR, PWM, WDT
Number of I/O:	28
Program Memory Size:	16KB (16K x 8)
Program Memory Type:	FLASH
EEPROM Size:	4K x 8
RAM Size:	2K x 8
Voltage - Supply (Vcc/Vdd):	2.4V ~ 5.5V
Data Converters:	A/D 9x8/10b
Oscillator Type:	Internal
Operating Temperature:	-40°C ~ 105°C (TA)
Mounting Type:	Surface Mount
Package / Case:	40-WFQFN Exposed Pad
Supplier Device Package:	40-HWQFN (6x6)

Alternative Products

Part Number	Manufacturer & Description	Compare
R5F100EAGNA#40 Match 100%	Renesas Electronics America IC MCU 16BIT 16KB FLASH 40HWQFN	R5F100EAGNA#20 vs R5F100EAGNA#40
R5F100EDGNA#20 Match 58%	Renesas Electronics America IC MCU 16BIT 48KB FLASH 40HWQFN	R5F100EAGNA#20 vs R5F100EDGNA#20
R5F104EAGNA#20 Match 92%	Renesas Electronics America IC MCU 16BIT 16KB FLASH 40HWQFN	R5F100EAGNA#20 vs R5F104EAGNA#20
R5F104EAGNA#40 Match 92%	Renesas Electronics America IC MCU 16BIT 16KB FLASH 40HWQFN	R5F100EAGNA#20 vs R5F104EAGNA#40
R5F100ECGNA#20 Match 74%	Renesas Electronics America IC MCU 16BIT 32KB FLASH 40HWQFN	R5F100EAGNA#20 vs R5F100ECGNA#20
R5F100ECGNA#40 Match 74%	Renesas Electronics America IC MCU 16BIT 32KB FLASH 40HWQFN	R5F100EAGNA#20 vs R5F100ECGNA#40
