MC9S08SH16CTJR

Part No :: MC9S08SH16CTJR

Manufacturer: NXP Semiconductors

VIGOR # :: 3649532

Description: IC MCU 8BIT 16KB FLASH 20TSSOP

Catalog: Embedded - Microcontrollers

DataSheet: MC9S08SH16CTJR PDF

Country of origin: -

Date code: -

MC9S08SH16CTJR Specifications

Type	Description
Series:	S08
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Core Processor:	S08
Core Size:	8-Bit
Speed:	40MHz
Connectivity:	I²C, LINbus, SCI, SPI
Peripherals:	LVD, POR, PWM, WDT
Number of I/O:	17
Program Memory Size:	16KB (16K x 8)
Program Memory Type:	FLASH
EEPROM Size:	-
RAM Size:	1K x 8
Voltage - Supply (Vcc/Vdd):	2.7V ~ 5.5V
Data Converters:	A/D 12x10b
Oscillator Type:	Internal
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	20-TSSOP (0.173", 4.40mm Width)
Supplier Device Package:	20-TSSOP
