Z8F2421PM020EC

Part No :: Z8F2421PM020EC

Manufacturer: Zilog / Littelfuse

VIGOR # :: 4804509

Description: IC MCU 8BIT 24KB FLASH 40DIP

Catalog: Embedded - Microcontrollers

DataSheet: Z8F2421PM020EC PDF

Country of origin: -

Date code: -

Z8F2421PM020EC Specifications

Type	Description
Series:	Encore!® XP®
Package:	Tube
Part Status:	Obsolete
Core Processor:	eZ8
Core Size:	8-Bit
Speed:	20MHz
Connectivity:	I²C, IrDA, SPI, UART/USART
Peripherals:	Brown-out Detect/Reset, DMA, POR, PWM, WDT
Number of I/O:	29
Program Memory Size:	24KB (24K x 8)
Program Memory Type:	FLASH
EEPROM Size:	-
RAM Size:	2K x 8
Voltage - Supply (Vcc/Vdd):	3V ~ 3.6V
Data Converters:	A/D 8x10b
Oscillator Type:	Internal
Operating Temperature:	-40°C ~ 105°C (TA)
Mounting Type:	Through Hole
Package / Case:	40-DIP (0.620", 15.75mm)
Supplier Device Package:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
Z8F1621PM020EG Match 78%	Zilog / Littelfuse IC MCU 8BIT 16KB FLASH 40DIP	Z8F2421PM020EC vs Z8F1621PM020EG
Z8F3201PM020EC Match 82%	VIGOR IC MCU 8BIT 32KB FLASH	Z8F2421PM020EC vs Z8F3201PM020EC
Z8F3221PM020EG Match 84%	Zilog / Littelfuse IC MCU 8BIT 32KB FLASH 40DIP	Z8F2421PM020EC vs Z8F3221PM020EG
Z8F4821PM020EG Match 62%	Zilog / Littelfuse IC MCU 8BIT 48KB FLASH 40DIP	Z8F2421PM020EC vs Z8F4821PM020EG
Z8F2401PM020EC Match 98%	VIGOR IC MCU 8BIT 24KB FLASH	Z8F2421PM020EC vs Z8F2401PM020EC
Z8F3221PM020EC Match 84%	Zilog / Littelfuse IC MCU 8BIT 32KB FLASH 40DIP	Z8F2421PM020EC vs Z8F3221PM020EC
