ADGS1409BCPZ-RL7

Part No :: ADGS1409BCPZ-RL7

Manufacturer: Linear Technology (Analog Devices, Inc.)

VIGOR # :: 3925651

Description: IC SWITCH DUAL 24LFCSP

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: ADGS1409BCPZ-RL7 PDF

Country of origin: -

Date code: -

ADGS1409BCPZ-RL7 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Active
Switch Circuit:	-
Multiplexer/Demultiplexer Circuit:	4:1
Number of Circuits:	2
On-State Resistance (Max):	4.7Ohm
Channel-to-Channel Matching (ΔRon):	200mOhm
Voltage - Supply, Single (V+):	12V
Voltage - Supply, Dual (V±):	±15V
Switch Time (Ton, Toff) (Max):	165ns, 155ns
-3db Bandwidth:	115MHz
Charge Injection:	50pC
Channel Capacitance (CS(off), CD(off)):	14pF, 40pF
Current - Leakage (IS(off)) (Max):	200pA
Crosstalk:	-70dB @ 1MHz
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	24-VFQFN Exposed Pad, CSP
Supplier Device Package:	24-LFCSP (4x4)
