ADG5434BCPZ-REEL7

Part No :: ADG5434BCPZ-REEL7

Manufacturer: Linear Technology (Analog Devices, Inc.)

VIGOR # :: 3926912

Description: IC SW ANLG QUAD SPDT 20LFCSP

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: ADG5434BCPZ-REEL7 PDF

Country of origin: -

Date code: -

ADG5434BCPZ-REEL7 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Switch Circuit:	SPDT
Multiplexer/Demultiplexer Circuit:	2:1
Number of Circuits:	4
On-State Resistance (Max):	14Ohm
Channel-to-Channel Matching (ΔRon):	300mOhm
Voltage - Supply, Single (V+):	9V ~ 40V
Voltage - Supply, Dual (V±):	±9V ~ 22V
Switch Time (Ton, Toff) (Max):	186ns, 104ns
-3db Bandwidth:	140MHz
Charge Injection:	176pC
Channel Capacitance (CS(off), CD(off)):	15pF, 23pF
Current - Leakage (IS(off)) (Max):	250pA
Crosstalk:	-60dB @ 1MHz
Operating Temperature:	-40°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Package / Case:	20-WFQFN Exposed Pad, CSP
Supplier Device Package:	20-LFCSP-WQ (4x4)
