MAX4560CPE+

Part No :: MAX4560CPE+

Manufacturer: Maxim Integrated

VIGOR # :: 4922420

Description: IC MUX/SW ANLG LV CMOS 16-DIP

Catalog: Interface - Analog Switches, Multiplexers, Demultiplexers

DataSheet: MAX4560CPE+ PDF

Country of origin: -

Date code: -

MAX4560CPE+ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Switch Circuit:	SPDT
Multiplexer/Demultiplexer Circuit:	2:1
Number of Circuits:	3
On-State Resistance (Max):	160Ohm
Channel-to-Channel Matching (ΔRon):	2Ohm
Voltage - Supply, Single (V+):	2V ~ 12V
Voltage - Supply, Dual (V±):	±2V ~ 6V
Switch Time (Ton, Toff) (Max):	150ns, 120ns
-3db Bandwidth:	-
Charge Injection:	2.4pC
Channel Capacitance (CS(off), CD(off)):	2pF, 4pF
Current - Leakage (IS(off)) (Max):	1nA
Crosstalk:	-93dB @ 100kHz
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Through Hole
Package / Case:	16-DIP (0.300", 7.62mm)
Supplier Device Package:	16-PDIP
