MAX4565CWP

Part No :: MAX4565CWP

Manufacturer: Maxim Integrated

VIGOR # :: 4956441

Description: IC VIDEO SWITCH QUAD SPST 20SOIC

Catalog: Interface - Analog Switches - Special Purpose

DataSheet: MAX4565CWP PDF

Country of origin: -

Date code: -

MAX4565CWP Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Applications:	Video
Multiplexer/Demultiplexer Circuit:	1:1
Switch Circuit:	SPST
Number of Channels:	4
On-State Resistance (Max):	60Ohm
Voltage - Supply, Single (V+):	2.7V ~ 12V
Voltage - Supply, Dual (V±):	±2.7V ~ 6V
-3db Bandwidth:	350MHz
Features:	Bi-Directional, T-Switch Configuration
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Surface Mount
Package / Case:	20-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	20-SOIC

Alternative Products

Part Number	Manufacturer & Description	Compare
MAX4545EWP+ Match 88%	VIGOR MAX4545 QUAD LOW-VOLTAGE, BIDIRE	MAX4565CWP vs MAX4545EWP+
MAX4545CWP+ Match 88%	Maxim Integrated IC VIDEO SWITCH QUAD SPST 20SOIC	MAX4565CWP vs MAX4545CWP+
MAX4545CWP Match 88%	VIGOR BIDIRECTIONAL RF/VIDEO SWITCH	MAX4565CWP vs MAX4545CWP
MAX4545EWP Match 88%	VIGOR BIDIRECTIONAL RF/VIDEO SWITCH	MAX4565CWP vs MAX4545EWP
MAX4545CWP+T Match 88%	Maxim Integrated IC VIDEO SWITCH QUAD SPST 20SOIC	MAX4565CWP vs MAX4545CWP+T
