SN74ACT534DWR

Part No :: SN74ACT534DWR

Manufacturer: VIGOR

VIGOR # :: 3823705

Description: SN74ACT534 OCTAL EDGE-TRIGGERED

Catalog: Logic - Flip Flops

DataSheet: SN74ACT534DWR PDF

Country of origin: -

Date code: -

SN74ACT534DWR Specifications

Type	Description
Series:	74ACT
Package:	Bulk
Part Status:	Active
Function:	Standard
Type:	D-Type
Output Type:	Tri-State, Inverted
Number of Elements:	1
Number of Bits per Element:	8
Clock Frequency:	100 MHz
Max Propagation Delay @ V, Max CL:	11.5ns @ 5V, 50pF
Trigger Type:	Positive Edge
Current - Output High, Low:	24mA, 24mA
Voltage - Supply:	4.5V ~ 5.5V
Current - Quiescent (Iq):	4 µA
Input Capacitance:	4.5 pF
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Supplier Device Package:	20-SOIC
Package / Case:	20-SOIC (0.295", 7.50mm Width)
