SN74HC109DT

Part No :: SN74HC109DT

Manufacturer: VIGOR

VIGOR # :: 3825520

Description: J-K FLIP-FLOP

Catalog: Logic - Flip Flops

DataSheet: SN74HC109DT PDF

Country of origin: -

Date code: -

SN74HC109DT Specifications

Type	Description
Series:	74HC
Package:	Bulk
Part Status:	Obsolete
Function:	Set(Preset) and Reset
Type:	JK Type
Output Type:	Complimentary
Number of Elements:	2
Number of Bits per Element:	1
Clock Frequency:	60 MHz
Max Propagation Delay @ V, Max CL:	30ns @ 6V, 50pF
Trigger Type:	Positive Edge
Current - Output High, Low:	5.2mA, 5.2mA
Voltage - Supply:	2V ~ 6V
Current - Quiescent (Iq):	4 µA
Input Capacitance:	3 pF
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Supplier Device Package:	16-SOIC
Package / Case:	16-SOIC (0.154", 3.90mm Width)
