M74HC109M1R

Part No :: M74HC109M1R

Manufacturer: STMicroelectronics

VIGOR # :: 4886054

Description: IC FF JK TYPE DUAL 1BIT 16SOP

Catalog: Logic - Flip Flops

DataSheet: M74HC109M1R PDF

Country of origin: -

Date code: -

M74HC109M1R Specifications

Type	Description
Series:	74HC
Package:	Tube
Part Status:	Obsolete
Function:	Set(Preset) and Reset
Type:	JK Type
Output Type:	Complimentary
Number of Elements:	2
Number of Bits per Element:	1
Clock Frequency:	67 MHz
Max Propagation Delay @ V, Max CL:	26ns @ 6V, 50pF
Trigger Type:	Positive Edge
Current - Output High, Low:	5.2mA, 5.2mA
Voltage - Supply:	2V ~ 6V
Current - Quiescent (Iq):	2 µA
Input Capacitance:	5 pF
Operating Temperature:	-55°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Supplier Device Package:	16-SOP
Package / Case:	16-SOIC (0.154", 3.90mm Width)

Alternative Products

Part Number	Manufacturer & Description	Compare
M74HC109RM13TR Match 100%	STMicroelectronics IC FF JK TYPE DUAL 1BIT 16SOP	M74HC109M1R vs M74HC109RM13TR
