SN74LS76AN

Part No :: SN74LS76AN

Manufacturer: Texas Instruments

VIGOR # :: 4886470

Description: IC FF JK TYPE DUAL 1BIT 16DIP

Catalog: Logic - Flip Flops

DataSheet: SN74LS76AN PDF

Country of origin: -

Date code: -

SN74LS76AN Specifications

Type	Description
Series:	74LS
Package:	Tube
Part Status:	Obsolete
Function:	Set(Preset) and Reset
Type:	JK Type
Output Type:	Complimentary
Number of Elements:	2
Number of Bits per Element:	1
Clock Frequency:	45 MHz
Max Propagation Delay @ V, Max CL:	20ns @ 5V, 15pF
Trigger Type:	Negative Edge
Current - Output High, Low:	400µA, 8mA
Voltage - Supply:	4.75V ~ 5.25V
Current - Quiescent (Iq):	4 mA
Input Capacitance:	-
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Through Hole
Supplier Device Package:	16-DIP
Package / Case:	16-DIP (0.300", 7.62mm)
