SN74LVC14APW

SN74LVC14APW Specifications

Type	Description
Series:	74LVC
Package:	Tube
Part Status:	Active
Logic Type:	Inverter
Number of Circuits:	6
Number of Inputs:	6
Features:	Schmitt Trigger
Voltage - Supply:	1.65V ~ 3.6V
Current - Quiescent (Max):	1 µA
Current - Output High, Low:	24mA, 24mA
Logic Level - Low:	0.15V ~ 0.8V
Logic Level - High:	1.3V ~ 2V
Max Propagation Delay @ V, Max CL:	6.2ns @ 3.3V, 50pF
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-TSSOP
Package / Case:	14-TSSOP (0.173", 4.40mm Width)

Alternative Products

Part Number	Manufacturer & Description	Compare
SN74LVC14APWTG4 Match 100%	Texas Instruments IC INVERTER 6CH 6-INP 14TSSOP	SN74LVC14APW vs SN74LVC14APWTG4
SN74LVC14APWT Match 100%	Texas Instruments IC INVERTER 6CH 6-INP 14TSSOP	SN74LVC14APW vs SN74LVC14APWT
SN74LVC14APWRG4 Match 100%	Texas Instruments IC INVERTER 6CH 6-INP 14TSSOP	SN74LVC14APW vs SN74LVC14APWRG4
SN74LVC14APWRG3 Match 100%	VIGOR IC INVERTER 6CH 6-INP 14TSSOP	SN74LVC14APW vs SN74LVC14APWRG3
SN74LVC14APWRE4 Match 100%	Texas Instruments IC INVERTER 6CH 6-INP 14TSSOP	SN74LVC14APW vs SN74LVC14APWRE4
SN74LVC14APWR Match 100%	Texas Instruments IC INVERTER 6CH 6-INP 14TSSOP	SN74LVC14APW vs SN74LVC14APWR
