SN74HC05DBRG4

Part No :: SN74HC05DBRG4

Manufacturer: Texas Instruments

VIGOR # :: 4884668

Description: IC INVERTER OD 6CH 6-INP 14SSOP

Catalog: Logic - Gates and Inverters

DataSheet: SN74HC05DBRG4 PDF

Country of origin: -

Date code: -

SN74HC05DBRG4 Specifications

Type	Description
Series:	74HC
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Logic Type:	Inverter
Number of Circuits:	6
Number of Inputs:	6
Features:	Open Drain
Voltage - Supply:	2V ~ 6V
Current - Quiescent (Max):	2 µA
Current - Output High, Low:	-, 5.2mA
Logic Level - Low:	0.5V ~ 1.8V
Logic Level - High:	1.5V ~ 4.2V
Max Propagation Delay @ V, Max CL:	20ns @ 6V, 50pF
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SSOP
Package / Case:	14-SSOP (0.209", 5.30mm Width)
