NC7SZ02P5X_F40

Part No :: NC7SZ02P5X_F40

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 4885458

Description: IC GATE NOR 1CH 2-INP SC70-5

Catalog: Logic - Gates and Inverters

DataSheet: NC7SZ02P5X_F40 PDF

Country of origin: -

Date code: -

NC7SZ02P5X_F40 Specifications

Type	Description
Series:	7SZ
Package:	Bulk
Part Status:	Obsolete
Logic Type:	NOR Gate
Number of Circuits:	1
Number of Inputs:	2
Features:	-
Voltage - Supply:	1.65V ~ 5.5V
Current - Quiescent (Max):	2 µA
Current - Output High, Low:	32mA, 32mA
Logic Level - Low:	-
Logic Level - High:	-
Max Propagation Delay @ V, Max CL:	4.3ns @ 5V, 50pF
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Supplier Device Package:	SC-70-5
Package / Case:	5-TSSOP, SC-70-5, SOT-353
