FAN5009M

Part No :: FAN5009M

Manufacturer: VIGOR

VIGOR # :: 3880024

Description: HALF BRIDGE BASED MOSFET DRIVER

Catalog: PMIC - Gate Drivers

DataSheet: FAN5009M PDF

Country of origin: -

Date code: -

FAN5009M Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Driven Configuration:	Half-Bridge
Channel Type:	Synchronous
Number of Drivers:	2
Gate Type:	N-Channel MOSFET
Voltage - Supply:	10V ~ 13.5V
Logic Voltage - VIL, VIH:	0.8V, 2.5V
Current - Peak Output (Source, Sink):	-
Input Type:	Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap):	15 V
Rise / Fall Time (Typ):	40ns, 20ns
Operating Temperature:	0°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
