FAN5701UC30X

Part No :: FAN5701UC30X

Manufacturer: VIGOR

VIGOR # :: 3922997

Description: LED DRIVER, 6-SEGMENT, PBGA16

Catalog: PMIC - LED Drivers

DataSheet: FAN5701UC30X PDF

Country of origin: -

Date code: -

FAN5701UC30X Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
Type:	DC DC Regulator
Topology:	Switched Capacitor (Charge Pump)
Internal Switch(s):	Yes
Number of Outputs:	6
Voltage - Supply (Min):	2.7V
Voltage - Supply (Max):	5.5V
Voltage - Output:	-
Current - Output / Channel:	30mA
Frequency:	1.2MHz
Dimming:	PWM
Applications:	Backlight
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-UFBGA, WLCSP
Supplier Device Package:	16-WLCSP (1.71x1.71)

Alternative Products

Part Number	Manufacturer & Description	Compare
TPS61195RUYR Match 85%	Texas Instruments IC LED DRIVER RGLTR DIM 28WQFN	FAN5701UC30X vs TPS61195RUYR
TPS61177ARGRR Match 100%	VIGOR TPS61177A WLED DRIVER FOR NOTEBO	FAN5701UC30X vs TPS61177ARGRR
SC5010ULTRT Match 100%	Semtech IC LED DRIVER CTRLR DIM 28MLPQ	FAN5701UC30X vs SC5010ULTRT
NCP5623DTBR2G Match 85%	Sanyo Semiconductor/ON Semiconductor IC LED DRIVER RGLTR 30MA 14TSSOP	FAN5701UC30X vs NCP5623DTBR2G
FAN5702UMP20X Match 100%	Sanyo Semiconductor/ON Semiconductor IC LED DRIVER RGLTR DIM 16UMLP	FAN5701UC30X vs FAN5702UMP20X
MP3384LGQ-Z Match 97%	MPS (Monolithic Power Systems) IC LED DRIVER	FAN5701UC30X vs MP3384LGQ-Z
