LM3560TLX/NOPB

Part No :: LM3560TLX/NOPB

Manufacturer: VIGOR

VIGOR # :: 3923441

Description: LED DRIVER, 2-SEGMENT

Catalog: PMIC - LED Drivers

DataSheet: LM3560TLX/NOPB PDF

Country of origin: -

Date code: -

LM3560TLX/NOPB Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Type:	DC DC Regulator
Topology:	Step-Up (Boost)
Internal Switch(s):	Yes
Number of Outputs:	2
Voltage - Supply (Min):	2.5V
Voltage - Supply (Max):	5.5V
Voltage - Output:	-
Current - Output / Channel:	1A (Flash)
Frequency:	2MHz
Dimming:	I²C
Applications:	Camera Flash
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-WFBGA, DSBGA
Supplier Device Package:	16-DSBGA (2.5x2.12)
