TPS2058DR

Part No :: TPS2058DR

Manufacturer: VIGOR

Description: POWER SUPPLY CIRCUIT, FIXED

Catalog: PMIC - Power Distribution Switches, Load Drivers

DataSheet: TPS2058DR PDF

Availability: 300 pieces

Unit Price: ~~$3.20000~~

Current price of TPS2058DR is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

TPS2058DR Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
Switch Type:	General Purpose
Number of Outputs:	4
Ratio - Input:Output:	2 x 1:2
Output Configuration:	High Side
Output Type:	N-Channel
Interface:	On/Off
Voltage - Load:	2.7V ~ 5.5V
Voltage - Supply (Vcc/Vdd):	Not Required
Current - Output (Max):	250mA
Rds On (Typ):	80mOhm
Input Type:	Non-Inverting
Features:	Status Flag
Fault Protection:	Current Limiting (Fixed), Over Temperature, UVLO
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	16-SOIC
Package / Case:	16-SOIC (0.154", 3.90mm Width)

Please confirm the specifications of the products when ordering.
