TPS22949AYZPR

Part No :: TPS22949AYZPR

Manufacturer: VIGOR

Description: TPS22949 4.5V, 0.2A, 350MOHM, 10

Catalog: PMIC - Power Distribution Switches, Load Drivers

DataSheet: TPS22949AYZPR PDF

Availability: 30000 pieces

Unit Price: ~~$0.72000~~

Current price of TPS22949AYZPR is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

TPS22949AYZPR Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Switch Type:	General Purpose
Number of Outputs:	2
Ratio - Input:Output:	1:1
Output Configuration:	High Side
Output Type:	P-Channel
Interface:	On/Off
Voltage - Load:	1.62V ~ 4.5V
Voltage - Supply (Vcc/Vdd):	Not Required
Current - Output (Max):	100mA
Rds On (Typ):	300mOhm
Input Type:	Non-Inverting
Features:	Auto Restart, Load Discharge
Fault Protection:	Current Limiting (Fixed), Over Temperature
Operating Temperature:	-40°C ~ 105°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	8-DSBGA, 8-WCSP (1.9x0.9)
Package / Case:	8-XFBGA, DSBGA
