MC33580BAPNA

Part No :: MC33580BAPNA

Manufacturer: NXP Semiconductors

VIGOR # :: 4902425

Description: IC PWR SWITCH N-CHAN 1:1 24PQFN

Catalog: PMIC - Power Distribution Switches, Load Drivers

DataSheet: MC33580BAPNA PDF

Country of origin: -

Date code: -

MC33580BAPNA Specifications

Type	Description
Series:	-
Package:	Tray
Part Status:	Obsolete
Switch Type:	General Purpose
Number of Outputs:	4
Ratio - Input:Output:	1:1
Output Configuration:	High Side
Output Type:	N-Channel
Interface:	SPI
Voltage - Load:	6V ~ 27V
Voltage - Supply (Vcc/Vdd):	4.5V ~ 5.5V
Current - Output (Max):	-
Rds On (Typ):	15mOhm
Input Type:	-
Features:	Slew Rate Controlled, Watchdog Timer
Fault Protection:	Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Operating Temperature:	-40°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	24-PQFN (12x12)
Package / Case:	24-PowerQFN
