TL494CDBR

Part No :: TL494CDBR

Manufacturer: VIGOR

VIGOR # :: 3851024

Description: SWITCHING CONTROLLER

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: TL494CDBR PDF

Country of origin: -

Date code: -

TL494CDBR Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
Output Type:	Transistor Driver
Function:	Step-Up, Step-Down, Step-Up/Step-Down
Output Configuration:	Positive
Topology:	Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
Number of Outputs:	2
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	7V ~ 40V
Frequency - Switching:	1kHz ~ 300kHz
Duty Cycle (Max):	45%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Dead Time Control, Frequency Control
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-SSOP (0.209", 5.30mm Width)
Supplier Device Package:	16-SSOP
