UCC3580N-3G4

Part No :: UCC3580N-3G4

Manufacturer: VIGOR

VIGOR # :: 3852178

Description: SWITCHING CONTROLLER

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: UCC3580N-3G4 PDF

Country of origin: -

Date code: -

UCC3580N-3G4 Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Output Type:	Transistor Driver
Function:	Step-Up/Step-Down
Output Configuration:	Positive or Negative
Topology:	Forward Converter
Number of Outputs:	2
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	8.5V ~ 16V
Frequency - Switching:	400kHz
Duty Cycle (Max):	66%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Enable, Ramp, Soft Start
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Through Hole
Package / Case:	16-DIP (0.300", 7.62mm)
Supplier Device Package:	16-PDIP
