UCC3813N-3

Part No :: UCC3813N-3

Manufacturer: VIGOR

VIGOR # :: 3852988

Description: UCC3813-3 LOW POWER ECONOMY BICM

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: UCC3813N-3 PDF

Country of origin: -

Date code: -

UCC3813N-3 Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Output Type:	Transistor Driver
Function:	Step-Up, Step-Up/Step-Down
Output Configuration:	Positive
Topology:	Boost, Flyback, Forward Converter
Number of Outputs:	1
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	3.6V ~ 12V
Frequency - Switching:	31kHz
Duty Cycle (Max):	99%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Frequency Control
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Through Hole
Package / Case:	8-DIP (0.300", 7.62mm)
Supplier Device Package:	8-PDIP
