UCC2806N

Part No :: UCC2806N

Manufacturer: VIGOR

VIGOR # :: 3853902

Description: UCC2806 LOW POWER, DUAL OUTPUT,

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: UCC2806N PDF

Country of origin: -

Date code: -

UCC2806N Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Output Type:	Transistor Driver
Function:	Step-Up, Step-Up/Step-Down
Output Configuration:	Positive, Isolation Capable
Topology:	Boost, Flyback, Forward Converter
Number of Outputs:	2
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	8V ~ 14.5V
Frequency - Switching:	47kHz
Duty Cycle (Max):	50%
Synchronous Rectifier:	Yes
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Current Limit, Enable, Frequency Control
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Through Hole
Package / Case:	16-DIP (0.300", 7.62mm)
Supplier Device Package:	16-PDIP
